| CD266
SERIES
ALUMINUM
ELECTROLYTIC CAPACITORS
|
|
| |
-
Long
useful life of 5000 hours at 105℃
-
Polarized capacitors; Non-solid; Pressure relief
-
High rated voltage, up to 450V
-
For Electronic Ballast, Lighting, Monitors, General
industrial use
-
Filtering of high voltages in power supplies
|
| Item |
Characteristics |
| Operating
Temperature Range(oC) |
-40~+105 |
-25~+105 |
|
Rated Voltage Range (V) |
160~250 |
350~450 |
| Nominal
capacitance range (uF) |
1~220 |
| Capacitance
Tolerance(20oC, 120Hz) |
+/-20% |
|
Leakage Current (uA) |
CV≤1000,
I≤0.02CV+40μA
(1 minute) ; CV>1000, I≤0.03CV+70μA
(1 minute)
C: Nominal Capacitance (μF), V: Rated Voltage (V) |
|
Dissipation Factor(20oC, 120Hz) |
| Rated
voltage (v) |
160 |
200 |
250 |
350 |
400 |
450 |
| D.F. |
0.12 |
0.12 |
0.12 |
0.15 |
0.15 |
0.20 |
|
|
Temperature Stability(100Hz) |
| Rated
voltage (v) |
160 |
200 |
250 |
Rated
voltage (v) |
350 |
400 |
450 |
|
Z-40℃/Z+20℃ |
4 |
4 |
4 |
Z-25℃/Z+20℃ |
6 |
6 |
6 |
|
| Load
Life(+105oC) |
| Time |
5000hours(Φ10: 4000hours) |
| Leakage
current |
Not more than the specified value |
| Capacitance
change |
withiną20% of initial value |
| Dissipation
Factor |
Not more than 300% of the specified value. |
|
| Shelf
Life (+105oC) |
| Time |
3000hours |
| Leakage
current |
Not more than 300% of the specified value |
| Capacitance
change |
withiną20% of initial value |
| Dissipation
Factor |
Not more than 200% of the specified value. |
After test: Rated voltage to be applied for 30minutes, 24 to
48 hours before measurement. |
|
|
- MULTIPLIER
FOR RIPPLE CURRENT
|
Lead spacing and diameter
| D+/-0.5 |
10 |
12.5 |
16 |
18 |
| F+/-0.5 |
5.0 |
5.0 |
7.5 |
7.5 |
|
d+/-0.1 |
0.6 |
0.6 |
0.8 |
0.8 |
|
a |
1.5 (L≤16);
2.0 (L>16) |
|
Frequency Coefficient
|
Freq(Hz) |
50,60 |
100 |
300 |
1K |
10K- |
|
Factor |
0.75 |
1.00 |
1.20 |
1.40 |
1.50 |
Temperature Coefficient
|
Temp.(
℃) |
+70 |
+85 |
+105 |
|
Factor |
1.8 |
1.4 |
1.0 |
|
|
WV |
160 |
200 |
250 |
| Size |
Z |
ESR |
Ripple |
Size |
Z |
ESR |
Ripple |
Size |
Z |
ESR |
Ripple |
|
Cap
(uF)
|
| DxL(mm) |
(ohm) |
(ohm) |
(mA) |
DxL(mm) |
(ohm) |
(ohm) |
(mA) |
DxL(mm) |
(ohm) |
(ohm) |
(mA) |
|
4.7 |
- |
- |
- |
- |
10x12.5 |
13.0 |
41 |
60 |
10x12.5 |
13.0 |
41 |
60 |
|
10 |
10x16 |
6.3 |
19 |
95 |
10x16 |
6.3 |
19 |
95 |
10x20 |
6.3 |
19 |
105 |
|
22 |
10x20 |
3.2 |
9 |
145 |
10x20 |
3.2 |
9 |
145 |
12.5x25 |
3.2 |
9 |
180 |
|
16x20 |
|
33 |
12.5x20 |
2.3 |
6 |
190 |
12.5x20 |
2.3 |
6 |
190 |
12.5x25 |
2.3 |
6 |
255 |
|
16x20 |
|
47 |
12.5x25 |
1.7 |
4 |
280 |
12.5x25 |
1.7 |
4 |
285 |
16x25 |
1.7 |
4 |
305 |
|
18x20 |
|
16x20 |
16x20 |
|
100 |
16x25 |
1.1 |
2 |
385 |
16X31.5 |
1.1 |
2 |
420 |
16X31.5 |
1.1 |
2 |
420 |
|
18x20 |
18X25 |
18X25 |
|
220 |
18x35.5 |
0.7 |
0.9 |
640 |
- |
- |
- |
- |
- |
- |
- |
- |
|
WV |
350 |
400 |
450 |
| Size |
Z |
ESR |
Ripple |
Size |
Z |
ESR |
Ripple |
Size |
Z |
ESR |
Ripple |
|
Cap
(uF)
|
| DxL(mm) |
(ohm) |
(ohm) |
(mA) |
DxL(mm) |
(ohm) |
(ohm) |
(mA) |
DxL(mm) |
(ohm) |
(ohm) |
(mA) |
|
1.0 |
- |
- |
- |
- |
- |
- |
- |
- |
10x12.5 |
94 |
318 |
30 |
|
2.2 |
- |
- |
- |
- |
10x12.5 |
33 |
109 |
45 |
10x16 |
43 |
145 |
50 |
|
3.3 |
10x12.5 |
22 |
72 |
50 |
10x16 |
22 |
72 |
50 |
10X20 |
29 |
96 |
65 |
|
4.7 |
10x16 |
16 |
51 |
65 |
10x20 |
16 |
51 |
70 |
12.5x20 |
20 |
68 |
80 |
|
10 |
12.5x20 |
7.6 |
24 |
120 |
12.5x20 |
7.6 |
24 |
120 |
16x20 |
10 |
32 |
140 |
|
22 |
12.5x25 |
3.8 |
11 |
180 |
16X25 |
3.8 |
11 |
205 |
16X31.5 |
4.6 |
14 |
225 |
|
16x20 |
18X20 |
18X25 |
|
33 |
16x25 |
2.6 |
7 |
210 |
16X31.5 |
2.6 |
7 |
250 |
18X35.5 |
3.4 |
10 |
285 |
|
18X25 |
|
47 |
16x35.5 |
2.0 |
4.5 |
305 |
18X31.5 |
2.0 |
5 |
315 |
- |
- |
- |
- |
|
18x31.5 |
Unless
otherwise specified, all electrical values apply at Tamb+20℃
Ripple
Current(mA rms) at 105℃,120Hz;
ESR: Equivalent series resistance at 120Hz (calculated from
tanδMax and CR); Z: Max impedance at 10KHz
The
specific capacitance and case size are available on request.
|
|
