Item |
Characteristics |
|
Operating
Temperature Range(oC) |
-55~+105 |
|
Rated
voltage Range (V) |
25~100 |
|
Nominal
capacitance range (uF) |
1~15 |
|
Capacitance Tolerance(20oC,120Hz) |
+/-20%
|
|
Leakage current (uA) |
I<=100(at 20oC,after 2 minutes) |
|
Dissipation Factor(20oC,120Hz) |
D.F.<=0.05
|
|
Load
Life(+105oC) |
| Time |
1000 hours with the polarity inverted every 250hours |
| Leakage Current |
Not more than the specified value. |
| Capacitance Change |
Within +/-15% of the initial value. |
| Dissipation Factor |
Not more than 200% of the specified value. |
|
|
Shelf
Life(+105oC) |
| Time |
500 hours |
| Leakage Current |
Not more than the specified value. |
| Capacitance Change |
Within +/-15% of the initial value. |
| Dissipation Factor |
Not more than 200% of the specified value. |
After test: Rated voltage to be applied for
30 minutes, 24 to 48 hours before measurement.
|
